The LS4200D outdoor distributed eNodeB integrates 4G LTE TDD radio access with flexible IP backhaul for rapid coverage deployment. It supports B40 and B41 operation and can be managed remotely through the HeMS network management system.
| Item | Specification |
|---|---|
| Radio Standard | 4G LTE TDD |
| Operating Frequency Bands | B40: 2300–2400 MHz B41: 2496–2690 MHz |
| Channel Bandwidth | 5/10/15/20 MHz |
| Duplex Mode | TDD |
| RF Channels | 2 |
| MIMO | 2T2R |
| Maximum Transmit Power | Up to 5 W/port |
| System Capacity | Support 128 active users and 384 RRC connection users |
| Synchronization | GPS / IEEE 1588v2 |
| Backhaul and Management | IP backhaul through Ethernet or optical interface Remote management through HeMS |
| Maximum Deployment Range | 4 km |
| Power Supply | DC 48 V |
| Operating Temperature | -40°C to +55°C |
| Operating Humidity | 10%–95% |
| Protection | IP65 |
| Installation Type | Wall or pole |
